Decoplex Structal

The industrial floor panel “Decoplex Structal” is based on high-grade veneered plywood. It has a highly abrasion-resistant and anti-slip face side which has a dissipative HPL finish on request, reverse side with HPL balancer. Suitable for applications such as skid conveyors, platforms and workstations.

Decoplex Structal

Compound element made of weatherproof glued plywood, face side with anti-slip, highly abrasion-resistant and optionally dissipative HPL. Reverse side has HPL balancer to our option. Edges protected by special edge sealing.

Note: Project-related cutting to size and CNC machining possible!

Overview of the technical data for the industrial panel “Decoplex Structal”:

Fire behaviour DIN EN 13501-1 Bfl -s1 (floor covering) test report no. 23 0004741-2 MPA-NRW
Anti-slip property DIN 51 130 Anti-slip class R10 test certificate no. 12 6236-S/10 MPI
Abrasion resistance DIN EN 13 329 AC 4
Optional: Dissipative capacity of surface DIN EN 61340-4-1 10^6 – 10^9 Ohm test certificate no. ST-12-05-31-01 DIN EN 61340-5-1

Persons/footwear/floor system

Rg < 3.5 * 10^7 Ohm fulfilled with ESD

Footwear (RSch = 7.0 * 10^6 Ohm)

Test certificate no. ST-12-05-31-01

Subject to design modifications. Important: reference values – these properties are not guaranteed, subject to technical modifications.
