Decoplex Structal FR

The flame-retardant industrial floor panel “Decoplex Structal FR” is based on high-grade veneered plywood. It has a highly abrasion-resistance and anti-slip face side which we can provide as a dissipative version on request. Reverse side with special aluminium laminate. Suitable for applications such as skid conveyors, platforms and workstations.

Decoplex Structal FR

The industrial floor panel “Decoplex Structal FR” (Fire Retardant) is a compound element made of waterproof glued veneered plywood. It has a highly abrasion-resistant and anti-slip face side which is optionally available with a dissipative HPL finish The special edge sealing protects the edges.

Note: Project-related cutting to size and CNC machining possible!



Overview of the technical data for the industrial panel “Decoplex Structal FR”:

  • Fire behaviour DIN EN 13501-1 B-s1, d0 (double floor) test report no. 23 0010362-5 MPA-NRW
  • Anti-slip property DIN 51 130 Anti-slip class R10 test certificate no. 12 6236-S/10 MPI
  • Abrasion resistance DIN EN 13 329 AC4
  • Optional: Dissipative capacity of surface DIN EN 61340-4-1 10^6 – 10^9 Ohm test certificate no. ST-12-05-31-01 DIN EN 61340-5-1
    • Persons/footwear/floor system
    • Rg < 3.5 * 10^7 Ohm fulfilled with ESD
    • Footwear (RSch = 7.0 * 10^6 Ohm)
    • Test certificate no. ST-12-05-31-01



Sample order
